| Frequency Response | 45Hz - 20KHz +/-3dB |
|---|---|
| Signal to Noise | 99dB |
| Input Impedance | 10K |
| Tweeter | Audax element 1” textile soft dome 4ohm with ADIMS baffle |
| Woofer | Silver Flute 5.5” 4ohm 25mm VC aluminum former |
| Power Supply | 28VDC 1.28A, AC 100-220V 1.0A, 50-60Hz |
| Amplifier | Class “D” 4x25W THD+N 0.08% at 1kHz (0.04% at 1W) |
| DSP | Analog Devices ADAU1707 (48000Hz Sampling Rate) |
| Dimensions | 7in W x 10.5in D x 12in H (17.8cm W x 26.7cm D x 30.5cm H) |
| Weight | 15lbs (6.8kg) |
| Warranty | Limited Lifetime |
